SF_EmergencyStop

This is the web edition of the original ‎⮫ AC500-S safety user manual, version 1.3.2. This web edition is provided for quick reference only. The original safety user manual must be used to meet functional safety application requirements.

Standards	Requirements
IEC 60204-1:2016	9.2.3.4 Emergency operations (emergency stop, emergency switching off) … The reset of the command shall not restart the machinery but only permit restarting.
ISO 13849-1:2015	5.2.2 Manual reset function
ISO 12100: 2010	6.2.11.4: Restart following power failure/spontaneous restart
ISO 13850:2015	Emergency Stop

This function block is a safety-related function block for monitoring an emergency stop button. This FB can be used for emergency switch off functionality (stop category 0), or - with additional peripheral support - as emergency stop (stop category 1 or 2).

Table 1029: FB name: SF_EmergencyStop
Name	Data type	Initial value	Description, parameter values
VAR_INPUT
Activate	BOOL	FALSE	⮫ Table 1012 “General input parameters”
S_EStopIn	BOOL	FALSE	Safety demand input. Variable. FALSE: Demand for safety-related response (e.g., emergency stop button is engaged). TRUE: No demand for safety-related response (e.g., emergency stop button not engaged).
S_StartReset	BOOL	FALSE	⮫ Table 1012 “General input parameters”
S_AutoReset	BOOL	FALSE	⮫ Table 1012 “General input parameters”
Reset	BOOL	FALSE	⮫ Table 1012 “General input parameters”
VAR_OUTPUT
Ready	BOOL	FALSE	⮫ Table 1013 “General output parameters”
S_EStopOut	BOOL	FALSE	Output for the safety-related response. FALSE: Safety output disabled. Demand for safety-related response (e.g., emergency stop button engaged, reset required or internal errors active) TRUE: Safety output enabled. No demand for safety-related response (e.g., emergency stop button not engaged, no internal errors active).
SafetyDemand	BOOL	FALSE	Optional. ⮫ Table 1013 “General output parameters”
ResetRequest	BOOL	FALSE	Optional. ⮫ Table 1013 “General output parameters”
Error	BOOL	FALSE	⮫ Table 1013 “General output parameters”
DiagCode	WORD	16#0000	⮫ Table 1013 “General output parameters”

Typical timing diagrams

SF_EmergencyStop_TimingDiagram_1 — Fig. 505: Timing diagram for SF_EmergencyStop: S_StartReset = FALSE, S_AutoReset = FALSE

SF_EmergencyStop_TimingDiagram_2 — Fig. 506: Timing diagram for SF_EmergencyStop: S_StartReset = TRUE, S_AutoReset = FALSE

SF_EmergencyStop_TimingDiagram_3 — Fig. 507: Timing diagram for SF_EmergencyStop: S_StartReset = FALSE, S_AutoReset = TRUE

Error detection

The function block detects a static TRUE signal at Reset input.

Error behavior

S_EStopOut is set to FALSE. In case of a static TRUE signal at the Reset input, the DiagCode output indicates the relevant error code and the Error output is set to TRUE.

To leave the error states, the Reset must be set to FALSE.

Function block-specific error and status codes

Table 1030: FB-specific error codes
DiagCode	State name	State description and output setting
C001	Reset Error 1	Reset is TRUE while waiting for S_EStopIn = TRUE. Ready = TRUE S_EStopOut = FALSE SafetyDemand = FALSE ResetRequest = FALSE Error = TRUE
C011	Reset Error 2	Reset is TRUE while waiting for S_EStopIn = TRUE. Ready = TRUE S_EStopOut = FALSE SafetyDemand = FALSE ResetRequest = FALSE Error = TRUE

Table 1031: FB-specific status codes (no error):
DiagCode	State name	State description and output setting
0000	Idle	The function block is not active (initial state). Ready = FALSE S_EStopOut = FALSE SafetyDemand = FALSE ResetRequest = FALSE Error = FALSE
8001	Init	Activation is TRUE. The function block was enabled. Check if S_StartReset is required. Ready = TRUE S_EStopOut = FALSE SafetyDemand = FALSE ResetRequest = FALSE Error = FALSE
8802	Wait for S_EstopIn 1	Activation is TRUE. Check if Reset is FALSE and wait for S_EStopIn = TRUE. Ready = TRUE S_EStopOut = FALSE SafetyDemand = TRUE ResetRequest = FALSE Error = FALSE
8402	Wait for Reset 1	Activation is TRUE. S_EStopIn = TRUE. Wait for rising trigger of Reset. Ready = TRUE S_EStopOut = FALSE SafetyDemand = FALSE ResetRequest = TRUE Error = FALSE
8804	Wait for S_EstopIn 2	Activation is TRUE. Safety demand detected. Check if Reset is FALSE and wait for S_EStopIn = TRUE. Ready = TRUE S_EStopOut = FALSE SafetyDemand = TRUE ResetRequest = FALSE Error = FALSE
8404	Wait for Reset 2	Activation is TRUE. S_EStopIn = TRUE. Check for S_AutoReset or wait for rising trigger of Reset. Ready = TRUE S_EStopOut = FALSE SafetyDemand = FALSE ResetRequest = TRUE Error = FALSE
8000	Safety Output Enabled	Activation is TRUE. S_EStopIn = TRUE. Functional mode with S_EStopOut = TRUE. Ready = TRUE S_EStopOut = TRUE SafetyDemand = FALSE ResetRequest = FALSE Error = FALSE
